A2212 2200kv Motor:
-KV: 2200
-Ri(M ): 0.033
-Battery: 2-3Li-Po
-Max Power: 342W
-Test Prop: 7x3/7x4
-Motor Size: 27.5x38mm/1.08''x1.5''
-Shaft Diameter: 3.17mm/0.12''
30A Brushless ESC:
-Compatible with: 400-450 helicopters / Aircraft or Quad-Rotor Multi RC Helicopter
-Output: Continuous 30A, Burst 40A up to 10 Secs.
-Input Voltage: 2-3cells lithium battery or 5-9 cells NiCd/NIMh battery.
-BEC: 2A / 5V (Linear mode).
-Max Speed: 210,000rpm for 2 Poles BLM, 70,000rpm for 6 poles BLM, 35,000rpm for 12 poles BLM. (BLM: BrushLess Motor)
SG90 9G Micro Servo:
-Translucent body, lightweight, less noise
-Weight: 9 grams
-No load speed: 0.12 sec / 60 deg (4.8 V)
-Locked-rotor torque: 1.5-1.7kg/cm (4.8V-6V)
-Operating temperature: -30 60 degrees Celsius
-Dead zone setting: 5 microseconds
-Working voltage: 4.8V-6V
Please Note:
When use this ESC and motor replacement at first time or you are not skillful or professional to play RC Plane Quadcopter Helicopter,
please follow these steps to set your throttle stroke calibration. Otherwise incorrect operating will cause ESC hot, smoke or burn.
How to set Throttle stroke calibration?
1. Connect the ESC with motor, another end connect with receiver.
2. Turn on the remote controller and push the throttle to the highest point.
3. Plug the ESC into batteries.
4. There has double click sound (the highest point of the throttle confirm).
5. After get the click sound take the throttle stick to the lowest point.
6. Confirm the three click sound that means OK.
Note: These three lines of the brushless ESC can be connected at will. If the steering is incorrect, you can adjust any two of them.
Package includes:
1 x 2200kv brushless motor
1 x 30A ESC
1 x Macroporous pulp(fit for Bullet)
1 x Holes pulp(fit for Pulp protection)
2 x SG90
